AVOS 600 G3 CEILING GRID IP44/20
AVOS 600 G3 CEILING GRID IP44/20

Všeobecni údaje
Application

Clean rooms

Product ShapeSquare
TypeClean rooms
MountingRecessed
Elektrická data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]20 - 50
IEC Protection ClassI
Optika
Diffuser MaterialPMMA
Diffuser Material DesignOPAL, MPR
TYPE OF CONTROLON/OFF, DALI
CONTROL SYSTEMON/OFF, DALI
LED LIFETIME Ta25 [h]L80B30 30.000h
Technická data
Total Consumption [W]20 - 50
Lumen Output [LM]2350 - 5300
Efficacy lm/Wup to 118
Diffuser MaterialPMMA
Body MaterialAnodized aluminium
Beam Angle [°]92°, 116°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
MacAdam step3
LED LIFETIME Ta25 [h]L80B30 30.000h
TYPE OF CONTROLON/OFF, DALI
Body ColorWhite 9016
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Popis:

A versatile, recessed luminaire with IP44/20 that can be used for applications with a higher humidity such as lavatories, open areas that require higher ingress protection.

Ke stažení:
Technický list:
1
Technické ilustrace:
1
Montážní pokyny:
1
Certifikáty:
1
Fotometrická data:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/DALI.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/AD - IP/20_44.svg
/soft4net/img/project/icons/J - MOUNTING/R.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_80.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_80.svg
Všeobecni údaje
Application

Clean rooms

Product ShapeSquare
TypeClean rooms
MountingRecessed
Elektrická data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]20 - 50
IEC Protection ClassI
Optika
Diffuser MaterialPMMA
Diffuser Material DesignOPAL, MPR
TYPE OF CONTROLON/OFF, DALI
CONTROL SYSTEMON/OFF, DALI
LED LIFETIME Ta25 [h]L80B30 30.000h
Technická data
Total Consumption [W]20 - 50
Lumen Output [LM]2350 - 5300
Efficacy lm/Wup to 118
Diffuser MaterialPMMA
Body MaterialAnodized aluminium
Beam Angle [°]92°, 116°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
MacAdam step3
LED LIFETIME Ta25 [h]L80B30 30.000h
TYPE OF CONTROLON/OFF, DALI
Body ColorWhite 9016
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Kryt
Body MaterialAnodized aluminium
Body ColorWhite 9016
FinishMatt, Gloss
Světelně-technická data
Light SourceLED
Total Consumption [W]20 - 50
Lumen Output [LM]2350 - 5300
Efficacy lm/Wup to 118
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
UGR<19
MacAdam step3
Beam Angle [°]92°, 116°
Light Distribution DIR/INDDIR
Technická data
TA [°C]0-25
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Generating PDF...

Varianty

Item
Code
Lenght
Width
Height
Diameter
W
Lumen
Output lm
Efficacy
lm/W
Diffuser
Beam
Angle
CRI
Color K
Type of
Control
IP
Color
AVOS 600 G3 CEILING GRID IP44/20 MPR 3900lm 42W 840 WH IP44/20 ON/OFFMI11015524955955953542390093MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 3900lm 42W 840 WH IP44/20 DALIMI11083877785955953542390093MPR92°804000DALI44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 4250lm 50W 840 WH IP44/20 ON/OFFMI11058001385955953550425085MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 4250lm 50W 840 WH IP44/20 DALIMI11042450765955953550425085MPR92°804000DALI44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2350lm 20W 840 WH IP44/20 ON/OFFMI110015484959559535202350118MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2350lm 20W 840 WH IP44/20 DALIMI110813790659559535202350118MPR92°804000DALI44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2650lm 24W 840 WH IP44/20 ON/OFFMI110867774159559535242650110MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2650lm 24W 840 WH IP44/20 DALIMI110020984459559535242650110MPR92°804000DALI44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2900lm 28W 840 WH IP44/20 ON/OFFMI110518766759559535282900104MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 2900lm 28W 840 WH IP44/20 DALIMI110563618859559535282900104MPR92°804000DALI44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 3200lm 32W 840 WH IP44/20 ON/OFFMI110797465159559535323200100MPR92°804000ON/OFF44/20WHITE
AVOS 600 G3 CEILING GRID IP44/20 MPR 3200lm 32W 840 WH IP44/20 DALIMI110639868659559535323200100MPR92°804000DALI44/20WHITE
