AVOS 600 SURFACE IP44/20
AVOS 600 SURFACE IP44/20

Všeobecni údaje
Application

Clean rooms

Product ShapeSquare
TypeClean rooms
MountingRecessed
Elektrická data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]20 - 58
IEC Protection ClassI
Optika
Diffuser MaterialPMMA
Diffuser Material DesignOPAL, MPR
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]L70B50 60.000h
Technická data
Total Consumption [W]20 - 58
Lumen Output [LM]1800 - 4600
Efficacy lm/Wup to 98
Diffuser MaterialPMMA
Body MaterialAnodized aluminium
Beam Angle [°]80°, 100°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]90
MacAdam step3
LED LIFETIME Ta25 [h]L70B50 60.000h
TYPE OF CONTROLON/OFF
Body ColorWhite 9016
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Popis:

A versatile, recessed luminaire with IP44/20 that can be used for applications with a higher humidity such as lavatories, open areas that require higher ingress protection.

Ke stažení:
Technický list:
1
Technické ilustrace:
1
Montážní pokyny:
1
Certifikáty:
1
Fotometrická data:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/AD - IP/20_44.svg
/soft4net/img/project/icons/J - MOUNTING/S.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_90.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_90.svg
Všeobecni údaje
Application

Clean rooms

Product ShapeSquare
TypeClean rooms
MountingRecessed
Elektrická data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]20 - 58
IEC Protection ClassI
Optika
Diffuser MaterialPMMA
Diffuser Material DesignOPAL, MPR
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]L70B50 60.000h
Technická data
Total Consumption [W]20 - 58
Lumen Output [LM]1800 - 4600
Efficacy lm/Wup to 98
Diffuser MaterialPMMA
Body MaterialAnodized aluminium
Beam Angle [°]80°, 100°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]90
MacAdam step3
LED LIFETIME Ta25 [h]L70B50 60.000h
TYPE OF CONTROLON/OFF
Body ColorWhite 9016
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Kryt
Body MaterialAnodized aluminium
Body ColorWhite 9016
FinishMatt, Gloss
Světelně-technická data
Light SourceLED
Total Consumption [W]20 - 58
Lumen Output [LM]1800 - 4600
Efficacy lm/Wup to 98
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]90
UGR<19
MacAdam step3
Beam Angle [°]80°, 100°
Light Distribution DIR/INDDIR
Technická data
TA [°C]0-25
Ingress Protection [IP]44/20
Mechanical Protection [IK]01
Generating PDF...

Varianty

Item
Code
Lenght
Width
Height
Diameter
W
Lumen
Output lm
Efficacy
lm/W
Diffuser
Beam
Angle
CRI
Color K
Type of
Control
IP
Color
AVOS 600 SURFACE IP44/20 OPAL 1800lm 20W 930 WH IP44/20 ON/OFFMI11023102315955955020180090OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 1900lm 20W 940 WH IP44/20 ON/OFFMI11077959865955955020190095OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2100lm 24W 930 WH IP44/20 ON/OFFMI11016631185955955024210088OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2200lm 24W 940 WH IP44/20 ON/OFFMI11095851085955955024220092OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2450lm 27W 930 WH IP44/20 ON/OFFMI11068248235955955027245091OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2550lm 27W 940 WH IP44/20 ON/OFFMI11084680305955955027255094OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2750lm 31W 930 WH IP44/20 ON/OFFMI11012900285955955031275089OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 2900lm 31W 940 WH IP44/20 ON/OFFMI11021653545955955031290094OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 3050lm 35W 930 WH IP44/20 ON/OFFMI11067082405955955035305087OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 3200lm 35W 940 WH IP44/20 ON/OFFMI11093959445955955035320091OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 3450lm 42W 930 WH IP44/20 ON/OFFMI11056168195955955042345082OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 3600lm 42W 940 WH IP44/20 ON/OFFMI11060848055955955042360086OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 3850lm 48W 930 WH IP44/20 ON/OFFMI11027649485955955048385080OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 4050lm 48W 940 WH IP44/20 ON/OFFMI11009346915955955048405084OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 4350lm 57W 930 WH IP44/20 ON/OFFMI11063452915955955057435076OPAL100°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 OPAL 4550lm 57W 940 WH IP44/20 ON/OFFMI11073724035955955057455080OPAL100°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 1850lm 20W 930 WH IP44/20 ON/OFFMI11063166555955955020185093MPR92°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 1950lm 20W 940 WH IP44/20 ON/OFFMI11017717505955955020195098MPR92°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2200lm 24W 930 WH IP44/20 ON/OFFMI11087088205955955024220092MPR92°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2250lm 24W 940 WH IP44/20 ON/OFFMI11060579975955955024225094MPR92°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2550lm 28W 930 WH IP44/20 ON/OFFMI11094021245955955028255091MPR92°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2600lm 28W 940 WH IP44/20 ON/OFFMI11046557675955955028260093MPR92°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2850lm 32W 930 WH IP44/20 ON/OFFMI11045648085955955032285089MPR92°903000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 2950lm 32W 940 WH IP44/20 ON/OFFMI11031145585955955032295092MPR92°904000ON/OFF44/20WHITE
AVOS 600 SURFACE IP44/20 MPR 3200lm 35W 930 WH IP44/20 ON/OFFMI11024932575955955035320091MPR92°903000ON/OFF44/20WHITE
