CAMEO MIDI
CAMEO MIDI

Všeobecni údaje

Application	It is ideal for offices, retail spaces, corridors, and social areas. For humid environments like bathrooms, an IP44-rated version is available. All models include a tempered glass cover to shield the reflector from humidity, dust and dirt.
Key Advantages	Featuring a high-performance, metallized, faceted plastic reflector, it ensures an efficient optical system with excellent light output. Aluminium trim ring in white as standard or any other colour on request.
Product Shape	Round
Type	Downlight
Mounting	Recessed
Mounting Opening	105

Elektrická data

Main Feed AC [V]	220-240V AC
Main Feed Frequency [Hz]	50-60
Total Consumption [W]	20, 25, 30
IEC Protection Class	II
Connector Type	Push-in

Optika

Optic Name	Metallized, fasetted plastic reflector
Diffuser Material	Tempered acrylic glass
TYPE OF CONTROL	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
CONTROL SYSTEM	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
LED LIFETIME Ta25 [h]	L70B50 ≥ 100 000h , L80B50 ≥ 100 000h, L90B50 ≥ 70 000h

Technická data

Total Consumption [W]	20, 25, 30
Lumen Output [LM]	1900, 2100, 3169
Efficacy lm/W	84 – 106
Diffuser Material	Tempered acrylic glass
Body Material	Cast aluminum
Beam Angle [°]	24, 36, 60
Light Distribution DIR/IND	DIR
LED Color Temperature CCT [K]	2700, 3000, 4000
Color Rendering Index [CRI]	80, 90
MacAdam step	<3
LED LIFETIME Ta25 [h]	L70B50 ≥ 100 000h , L80B50 ≥ 100 000h, L90B50 ≥ 70 000h
TYPE OF CONTROL	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
Body Color	White
Ingress Protection [IP]	20, 44
Main Feed AC [V]	220-240V AC
Diameter ø [mm]	115
Weight [KG]	0.72 kg

Popis:

CAMEO MIDI is a recessed downlight designed for essential lighting needs.
Offering 50° light distributions, three lumen output options in three power options 20, 25, 30 W.
Reflector housing in die-casted aluminium, metallised plastic SF reflector and driver housing in polycarbonate.

Please note that lighting parameters for CRI90 may vary by +/- 10%.

Optional:

Black color available on request
IP44 available on request
CRI97 available on request

Key Advantages:

Featuring a high-performance, metallized, faceted plastic reflector, it ensures an efficient optical system with excellent light output.
Aluminium trim ring in white as standard or any other colour on request.

Ke stažení:

Technický list:

Technické ilustrace:

Montážní pokyny:

Certifikáty:

Fotometrická data:

Všeobecni údaje

Application	It is ideal for offices, retail spaces, corridors, and social areas. For humid environments like bathrooms, an IP44-rated version is available. All models include a tempered glass cover to shield the reflector from humidity, dust and dirt.
Key Advantages	Featuring a high-performance, metallized, faceted plastic reflector, it ensures an efficient optical system with excellent light output. Aluminium trim ring in white as standard or any other colour on request.
Product Shape	Round
Type	Downlight
Mounting	Recessed
Mounting Opening	105

Elektrická data

Main Feed AC [V]	220-240V AC
Main Feed Frequency [Hz]	50-60
Total Consumption [W]	20, 25, 30
IEC Protection Class	II
Connector Type	Push-in

Optika

Optic Name	Metallized, fasetted plastic reflector
Diffuser Material	Tempered acrylic glass
TYPE OF CONTROL	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
CONTROL SYSTEM	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
LED LIFETIME Ta25 [h]	L70B50 ≥ 100 000h , L80B50 ≥ 100 000h, L90B50 ≥ 70 000h

Technická data

Total Consumption [W]	20, 25, 30
Lumen Output [LM]	1900, 2100, 3169
Efficacy lm/W	84 – 106
Diffuser Material	Tempered acrylic glass
Body Material	Cast aluminum
Beam Angle [°]	24, 36, 60
Light Distribution DIR/IND	DIR
LED Color Temperature CCT [K]	2700, 3000, 4000
Color Rendering Index [CRI]	80, 90
MacAdam step	<3
LED LIFETIME Ta25 [h]	L70B50 ≥ 100 000h , L80B50 ≥ 100 000h, L90B50 ≥ 70 000h
TYPE OF CONTROL	ON/OFF, DALI, 1-10V, TRIAC DIM, ZIGBEE, BT
Body Color	White
Ingress Protection [IP]	20, 44
Main Feed AC [V]	220-240V AC
Diameter ø [mm]	115
Weight [KG]	0.72 kg

Kryt

Body Material	Cast aluminum
Body Color	White

Světelně-technická data

Light Source	COB LED
Total Consumption [W]	20, 25, 30
Lumen Output [LM]	1900, 2100, 3169
Efficacy lm/W	84 – 106
LED Color Temperature CCT [K]	2700, 3000, 4000
Color Rendering Index [CRI]	80, 90
MacAdam step	<3
Beam Angle [°]	24, 36, 60
Light Distribution DIR/IND	DIR

Technická data

TA [°C]	0 to +25
Ingress Protection [IP]	20, 44

Rozměry

Diameter ø [mm]	115
Weight [KG]	0.72 kg

Varianty

Item	Code	Height	Diameter	W	Lumen Output lm	Efficacy lm/W	Diffuser	Beam Angle	CRI	Color K	Type of Control	IP	Color
CAMEO MIDI CLEAR 1900lm 20W 827 115 Wh IP20 ON/OFF	MI4631432	98	115	20	1900	95	CLEAR	50	80	2700	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 830 115 Wh IP20 ON/OFF	MI5478606	98	115	20	1900	95	CLEAR	50	80	3000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 840 115 Wh IP20 ON/OFF	MI6837160	98	115	20	1900	95	CLEAR	50	80	4000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 827 115 Wh IP20 DALI	MI306086	98	115	20	1900	95	CLEAR	50	80	2700	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 830 115 Wh IP20 DALI	MI1296811	98	115	20	1900	95	CLEAR	50	80	3000	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 840 115 Wh IP20 DALI	MI5246439	98	115	20	1900	95	CLEAR	50	80	4000	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 827 115 Wh IP20 TRIAC-DIM	MI3196505	98	115	20	1900	95	CLEAR	50	80	2700	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 830 115 Wh IP20 TRIAC-DIM	MI9498959	98	115	20	1900	95	CLEAR	50	80	3000	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 840 115 Wh IP20 TRIAC-DIM	MI800740	98	115	20	1900	95	CLEAR	50	80	4000	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 927 115 Wh IP20 ON/OFF	MI9276179	98	115	20	1900	95	CLEAR	50	90	2700	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 930 115 Wh IP20 ON/OFF	MI8406249	98	115	20	1900	95	CLEAR	50	90	3000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 940 115 Wh IP20 ON/OFF	MI8511574	98	115	20	1900	95	CLEAR	50	90	4000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 927 115 Wh IP20 DALI	MI490365	98	115	20	1900	95	CLEAR	50	90	2700	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 930 115 Wh IP20 DALI	MI6744113	98	115	20	1900	95	CLEAR	50	90	3000	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 940 115 Wh IP20 DALI	MI9056321	98	115	20	1900	95	CLEAR	50	90	4000	DALI	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 927 115 Wh IP20 TRIAC-DIM	MI19375	98	115	20	1900	95	CLEAR	50	90	2700	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 930 115 Wh IP20 TRIAC-DIM	MI3421086	98	115	20	1900	95	CLEAR	50	90	3000	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 1900lm 20W 940 115 Wh IP20 TRIAC-DIM	MI218471	98	115	20	1900	95	CLEAR	50	90	4000	TRIAC-DIM	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 827 115 Wh IP20 ON/OFF	MI4452762	98	115	25	2100	84	CLEAR	50	80	2700	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 830 115 Wh IP20 ON/OFF	MI9027527	98	115	25	2100	84	CLEAR	50	80	3000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 840 115 Wh IP20 ON/OFF	MI8711303	98	115	25	2100	84	CLEAR	50	80	4000	ON/OFF	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 827 115 Wh IP20 DALI	MI6690830	98	115	25	2100	84	CLEAR	50	80	2700	DALI	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 830 115 Wh IP20 DALI	MI8195611	98	115	25	2100	84	CLEAR	50	80	3000	DALI	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 840 115 Wh IP20 DALI	MI3178748	98	115	25	2100	84	CLEAR	50	80	4000	DALI	20	WHITE
CAMEO MIDI CLEAR 2100lm 25W 827 115 Wh IP20 TRIAC-DIM	MI8532680	98	115	25	2100	84	CLEAR	50	80	2700	TRIAC-DIM	20	WHITE

Zobrazit na stránku: 25 / 50 / 75 / 100 | Stránka 1 z 3
