MIPLANTS MINI
MIPLANTS MINI

Všeobecni údaje
Application

Horticulture light - for plants only
Optimal lighting for plants breeding

Product ShapeRectangular
TypeReflector
MountingSURFACE, WALL
Elektrická data
Main Feed AC [V]220 - 240
Main Feed Frequency [Hz]50-60
Total Consumption [W]33
IEC Protection ClassI, II
Optika
Optic NameLens
Diffuser MaterialTempered glass
Diffuser Material DesignLENS
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]109 000 500mA, 45 600 1000mA
Technická data
Total Consumption [W]33
Lumen Output [LM]2200- 2500
Efficacy lm/W67, 75
Diffuser MaterialTempered glass
Body MaterialALUMINIUM
Beam Angle [°]15°, 35°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]FLOWERING , VEGETATION
MacAdam step3
LED LIFETIME Ta25 [h]109 000 500mA, 45 600 1000mA
TYPE OF CONTROLON/OFF
Body ColorBlack
Main Feed AC [V]220 - 240
Popis:

The MIPLANTS series was designed using modern simulation methods in order to obtain the highest product quality
▪ Based on CREE® LEDs
▪ Vegetation or Flowering version
▪ 15° or 35° beam angle
▪ 12V/24V DC
▪ 5-year warranty

Ke stažení:
Technický list:
1
Montážní pokyny:
1
Certifikáty:
1
Fotometrická data:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/W - HOUSING COLOR/BLACK.svg
Všeobecni údaje
Application

Horticulture light - for plants only
Optimal lighting for plants breeding

Product ShapeRectangular
TypeReflector
MountingSURFACE, WALL
Elektrická data
Main Feed AC [V]220 - 240
Main Feed Frequency [Hz]50-60
Total Consumption [W]33
IEC Protection ClassI, II
Optika
Optic NameLens
Diffuser MaterialTempered glass
Diffuser Material DesignLENS
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]109 000 500mA, 45 600 1000mA
Technická data
Total Consumption [W]33
Lumen Output [LM]2200- 2500
Efficacy lm/W67, 75
Diffuser MaterialTempered glass
Body MaterialALUMINIUM
Beam Angle [°]15°, 35°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]FLOWERING , VEGETATION
MacAdam step3
LED LIFETIME Ta25 [h]109 000 500mA, 45 600 1000mA
TYPE OF CONTROLON/OFF
Body ColorBlack
Main Feed AC [V]220 - 240
Kryt
Body MaterialALUMINIUM
Body ColorBlack
FinishElectrostatic powder coated
Světelně-technická data
Light SourceLED
Total Consumption [W]33
Lumen Output [LM]2200- 2500
Efficacy lm/W67, 75
LED Color Temperature CCT [K]FLOWERING , VEGETATION
MacAdam step3
Beam Angle [°]15°, 35°
Light Distribution DIR/INDDIR
Technická data
TA [°C]-20 to +40
