ORTUS 100 SURFACE
ORTUS 100 SURFACE

Všeobecni údaje

Application	A version with a CRI>90 makes the product suitable for use in museums, galleries, premium boutiques and dental offices.
Key Advantages	Various optic beam angle versions designed to suit any applications and requirements.
Product Shape	Round
Type	Spotlight
Mounting	Surface

Elektrická data

Main Feed AC [V]	220-240
Main Feed Frequency [Hz]	50-60
Total Consumption [W]	12 - 23
IEC Protection Class	I

Optika

Diffuser Material	PLX
Diffuser Material Design	Transparent, Frost
TYPE OF CONTROL	ON/OFF
CONTROL SYSTEM	ON/OFF
LED LIFETIME Ta25 [h]	L70B50 50.000h

Technická data

Total Consumption [W]	12 - 23
Lumen Output [LM]	1350 - 2800
Efficacy lm/W	up to 122
Diffuser Material	PLX
Body Material	Anodized aluminium
Beam Angle [°]	22°, 26°, 56°
Light Distribution DIR/IND	DIR
LED Color Temperature CCT [K]	3000, 4000
Color Rendering Index [CRI]	90
MacAdam step	3
LED LIFETIME Ta25 [h]	L70B50 50.000h
TYPE OF CONTROL	ON/OFF
Body Color	White 9016, Black 9005, Gray 9016
Ingress Protection [IP]	44
Mechanical Protection [IK]	01
Main Feed AC [V]	220-240
Diameter ø [mm]	106

Popis:

A small, configurable spotlight – surface downlight for interior lighting. A wide range of technical parameter and luminaire appearance variants for versatile applications. COB technology and a high-performance, metalized, facetted plastic reflector guarantee the optimum construction of the optical system and a high efficiency. The tempered transparent glass protects the luminaire against dust, dirt. A ring or frame made of die-cast aluminium or steel sheet, painted white or black as a standard.

Key Advantages:

Various optic beam angle versions designed to suit any applications and requirements.

Ke stažení:

Technický list:

Technické ilustrace:

Montážní pokyny:

Certifikáty:

Fotometrická data:

Všeobecni údaje

Application	A version with a CRI>90 makes the product suitable for use in museums, galleries, premium boutiques and dental offices.
Key Advantages	Various optic beam angle versions designed to suit any applications and requirements.
Product Shape	Round
Type	Spotlight
Mounting	Surface

Elektrická data

Main Feed AC [V]	220-240
Main Feed Frequency [Hz]	50-60
Total Consumption [W]	12 - 23
IEC Protection Class	I

Optika

Diffuser Material	PLX
Diffuser Material Design	Transparent, Frost
TYPE OF CONTROL	ON/OFF
CONTROL SYSTEM	ON/OFF
LED LIFETIME Ta25 [h]	L70B50 50.000h

Technická data

Total Consumption [W]	12 - 23
Lumen Output [LM]	1350 - 2800
Efficacy lm/W	up to 122
Diffuser Material	PLX
Body Material	Anodized aluminium
Beam Angle [°]	22°, 26°, 56°
Light Distribution DIR/IND	DIR
LED Color Temperature CCT [K]	3000, 4000
Color Rendering Index [CRI]	90
MacAdam step	3
LED LIFETIME Ta25 [h]	L70B50 50.000h
TYPE OF CONTROL	ON/OFF
Body Color	White 9016, Black 9005, Gray 9016
Ingress Protection [IP]	44
Mechanical Protection [IK]	01
Main Feed AC [V]	220-240
Diameter ø [mm]	106

Kryt

Body Material	Anodized aluminium
Body Color	White 9016, Black 9005, Gray 9016
Finish	Matt, Gloss

Světelně-technická data

Light Source	LED
Total Consumption [W]	12 - 23
Lumen Output [LM]	1350 - 2800
Efficacy lm/W	up to 122
LED Color Temperature CCT [K]	3000, 4000
Color Rendering Index [CRI]	90
MacAdam step	3
Beam Angle [°]	22°, 26°, 56°
Light Distribution DIR/IND	DIR

Technická data

TA [°C]	0-25
Ingress Protection [IP]	44
Mechanical Protection [IK]	01

Rozměry

Diameter ø [mm]	106

Varianty

Item	Code	Height	W	Lumen Output lm	Efficacy lm/W	Diffuser	Beam Angle	CRI	Color K	Type of Control	IP	Color
ORTUS 100 SURFACE TRANSPARENT 1350lm 12W 930 WH IP44 ON/OFF	MI101650074	120	12	1350	113	TRANSPARENT	22°	90	3000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 WH IP44 ON/OFF	MI104398217	120	12	1450	121	TRANSPARENT	22°	90	4000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1350lm 12W 930 GR IP44 ON/OFF	MI102980387	120	12	1350	113	TRANSPARENT	22°	90	3000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 GR IP44 ON/OFF	MI104450759	120	12	1450	121	TRANSPARENT	22°	90	4000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1350lm 12W 930 BL IP44 ON/OFF	MI106122776	120	12	1350	113	TRANSPARENT	22°	90	3000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 BL IP44 ON/OFF	MI106684634	120	12	1450	121	TRANSPARENT	22°	90	4000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1400lm 12W 930 WH IP44 ON/OFF	MI103039523	120	12	1400	117	TRANSPARENT	56°	90	3000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 WH IP44 ON/OFF	MI104905584	120	12	1450	121	TRANSPARENT	56°	90	4000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1400lm 12W 930 GR IP44 ON/OFF	MI109024406	120	12	1400	117	TRANSPARENT	56°	90	3000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 GR IP44 ON/OFF	MI104661264	120	12	1450	121	TRANSPARENT	56°	90	4000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1400lm 12W 930 BL IP44 ON/OFF	MI101585973	120	12	1400	117	TRANSPARENT	56°	90	3000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1450lm 12W 940 BL IP44 ON/OFF	MI109147838	120	12	1450	121	TRANSPARENT	56°	90	4000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1800lm 16W 930 WH IP44 ON/OFF	MI106428648	120	16	1800	113	TRANSPARENT	22°	90	3000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1900lm 16W 940 WH IP44 ON/OFF	MI105759418	120	16	1900	119	TRANSPARENT	22°	90	4000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1800lm 16W 930 GR IP44 ON/OFF	MI109294533	120	16	1800	113	TRANSPARENT	22°	90	3000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1900lm 16W 940 GR IP44 ON/OFF	MI108669103	120	16	1900	119	TRANSPARENT	22°	90	4000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1800lm 16W 930 BL IP44 ON/OFF	MI100460270	120	16	1800	113	TRANSPARENT	22°	90	3000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1900lm 16W 940 BL IP44 ON/OFF	MI102251549	120	16	1900	119	TRANSPARENT	22°	90	4000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1850lm 16W 930 WH IP44 ON/OFF	MI101893755	120	16	1850	116	TRANSPARENT	56°	90	3000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1950lm 16W 940 WH IP44 ON/OFF	MI101552557	120	16	1950	122	TRANSPARENT	56°	90	4000	ON/OFF	44	WHITE
ORTUS 100 SURFACE TRANSPARENT 1850lm 16W 930 GR IP44 ON/OFF	MI108692849	120	16	1850	116	TRANSPARENT	56°	90	3000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1950lm 16W 940 GR IP44 ON/OFF	MI109631283	120	16	1950	122	TRANSPARENT	56°	90	4000	ON/OFF	44	GREY
ORTUS 100 SURFACE TRANSPARENT 1850lm 16W 930 BL IP44 ON/OFF	MI106599762	120	16	1850	116	TRANSPARENT	56°	90	3000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 1950lm 16W 940 BL IP44 ON/OFF	MI109854736	120	16	1950	122	TRANSPARENT	56°	90	4000	ON/OFF	44	BLACK
ORTUS 100 SURFACE TRANSPARENT 2250lm 19W 930 WH IP44 ON/OFF	MI104781763	120	19	2250	118	TRANSPARENT	22°	90	3000	ON/OFF	44	WHITE
