ARON SURFACE IP65
ARON SURFACE IP65

General data
Application

Application offices, shops, entrance halls, parking areas.

Key Advantages

Easily mounted to ceiling or wall.

TypeDustproof
MountingSurface
Electrical data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]19 - 50
IEC Protection ClassI
Optics
Diffuser MaterialPMMA
Diffuser Material DesignPLX
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]L80B10 60.000h
Technical data
Total Consumption [W]19 - 50
Lumen Output [LM]2300 - 7250
Efficacy lm/Wup to 145
Diffuser MaterialPMMA
Beam Angle [°]128°, 100°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
MacAdam step3
LED LIFETIME Ta25 [h]L80B10 60.000h
TYPE OF CONTROLON/OFF
Body ColorGray 9006
Ingress Protection [IP]65
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Description:

A versatile and robust luminaire with IP65 suitable for a wide range of applications. The diffuser and housing are made of UV-stabilized polycarbonate with stainless steel mounting brackets.

Key Advantages:

Easily mounted to ceiling or wall.

Downloads:
Datasheet:
1
Technical illustrations:
1
Mounting instructions:
1
Certificates:
1
Photometric data:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/AD - IP/65.svg
/soft4net/img/project/icons/J - MOUNTING/S.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_80.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_80.svg
General data
Application

Application offices, shops, entrance halls, parking areas.

Key Advantages

Easily mounted to ceiling or wall.

TypeDustproof
MountingSurface
Electrical data
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]19 - 50
IEC Protection ClassI
Optics
Diffuser MaterialPMMA
Diffuser Material DesignPLX
TYPE OF CONTROLON/OFF
CONTROL SYSTEMON/OFF
LED LIFETIME Ta25 [h]L80B10 60.000h
Technical data
Total Consumption [W]19 - 50
Lumen Output [LM]2300 - 7250
Efficacy lm/Wup to 145
Diffuser MaterialPMMA
Beam Angle [°]128°, 100°
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
MacAdam step3
LED LIFETIME Ta25 [h]L80B10 60.000h
TYPE OF CONTROLON/OFF
Body ColorGray 9006
Ingress Protection [IP]65
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Housing
Body ColorGray 9006
FinishMatt, Gloss
Light technical data
Light SourceLED
Total Consumption [W]19 - 50
Lumen Output [LM]2300 - 7250
Efficacy lm/Wup to 145
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80
MacAdam step3
Beam Angle [°]128°, 100°
Light Distribution DIR/INDDIR
Technical data
TA [°C]0-25
Ingress Protection [IP]65
Mechanical Protection [IK]01
Generating PDF...

Variations

Item
Code
Lenght
Width
Height
Diameter
W
Lumen
Output lm
Efficacy
lm/W
Diffuser
Beam
Angle
CRI
Color K
Type of
Control
IP
Color
ARON SURFACE IP65 OPAL 2300lm 19W 830 614 GR IP65 ON/OFFMI11181472696146968192300121OPAL125°X103°803000ON/OFF65GREY
ARON SURFACE IP65 OPAL 2300lm 19W 840 614 GR IP65 ON/OFFMI11148600986146968192300121OPAL125°X103°804000ON/OFF65GREY
ARON SURFACE IP65 OPAL 4300lm 33W 830 1174 GR IP65 ON/OFFMI111007790911746968334300130OPAL125°X103°803000ON/OFF65GREY
ARON SURFACE IP65 OPAL 4300lm 33W 840 1174 GR IP65 ON/OFFMI111041110411746968334300130OPAL125°X103°804000ON/OFF65GREY
ARON SURFACE IP65 OPAL 6000lm 47W 830 1454 GR IP65 ON/OFFMI111392180914546968476000128OPAL125°X103°803000ON/OFF65GREY
ARON SURFACE IP65 OPAL 6000lm 47W 840 1454 GR IP65 ON/OFFMI111363998514546968476000128OPAL125°X103°804000ON/OFF65GREY
ARON SURFACE IP65 OPAL 7250lm 50W 840 1174 GR IP65 ON/OFFMI111860307311746968507250145OPAL125°X103°804000ON/OFF65GREY
