TOKO SII
TOKO SII

General data
Application

All-around sport applications, manufactories, logistic facilities and large outdoor areas, parking lots

Key Advantages

6 different symmetric and asymmetric beam angle options

Product ShapeRECTANGULAR
TypeFLOODLIGHT
MountingPOLE, SURFACE
Electrical data
Main Feed AC [V]90 - 305
Main Feed Frequency [Hz]50-60
Total Consumption [W]1200
IEC Protection ClassI, II
Optics
Optic NameLens
Diffuser Material4mm tempered glass
Diffuser Material DesignPMMA UV resistant LENS
TYPE OF CONTROLON/OFF
LED LIFETIME Ta25 [h]100 000h
Technical data
Total Consumption [W]1200
Lumen Output [LM]144000 - 156000
Efficacy lm/W130
Diffuser Material4mm tempered glass
Body MaterialAluminium injection body
Beam Angle [°]15°, 18°, 30°, 40°, 60°, 90°, 86x105° asym
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000, 6500
Color Rendering Index [CRI]70
MacAdam step3
LED LIFETIME Ta25 [h]100 000h
TYPE OF CONTROLON/OFF
Body ColorBlack, Grey, White
Ingress Protection [IP]66
Mechanical Protection [IK]08
Main Feed AC [V]90 - 305
Weight [KG]32.00 kg
Description:

Powerful and long-lasting maintenance free floodlight combining efficient LED technology and design in a single product with various power options and beam angles options
BODY
Aluminium injection body, electrostatic powder coated
4mm tempered glass, ventilation plug
LED
100.000 hours LED lifetime according to LM-80 and TM-21 report
DRIVER
Constant current output, With 90% efficiency, Effective power factor regulation that is not affected by fluctuations in grid voltage, dimmable-programmable ENEC certificated IP67 Driver
LENS
Resistant to UV rays, 93% optically efficient PMMA material lens
PCB
Aluminum PCB, Aluminum Base Layer / Thickness: 1L / 1.6mm
Copper Thickness: 1 OZ,HASL surface coating
OPTIONS
SPD, IP68 Connector

Key Advantages:

6 different symmetric and asymmetric beam angle options

Downloads:
Datasheet:
1
Mounting instructions:
1
Certificates:
1
Photometric data:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/AD - IP/66.svg
/soft4net/img/project/icons/W - HOUSING COLOR/BLACK.svg
/soft4net/img/project/icons/W - HOUSING COLOR/GREY.svg
/soft4net/img/project/icons/W - HOUSING COLOR/WHITE.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_70.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_70.svg
General data
Application

All-around sport applications, manufactories, logistic facilities and large outdoor areas, parking lots

Key Advantages

6 different symmetric and asymmetric beam angle options

Product ShapeRECTANGULAR
TypeFLOODLIGHT
MountingPOLE, SURFACE
Electrical data
Main Feed AC [V]90 - 305
Main Feed Frequency [Hz]50-60
Total Consumption [W]1200
IEC Protection ClassI, II
Optics
Optic NameLens
Diffuser Material4mm tempered glass
Diffuser Material DesignPMMA UV resistant LENS
TYPE OF CONTROLON/OFF
LED LIFETIME Ta25 [h]100 000h
Technical data
Total Consumption [W]1200
Lumen Output [LM]144000 - 156000
Efficacy lm/W130
Diffuser Material4mm tempered glass
Body MaterialAluminium injection body
Beam Angle [°]15°, 18°, 30°, 40°, 60°, 90°, 86x105° asym
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000, 6500
Color Rendering Index [CRI]70
MacAdam step3
LED LIFETIME Ta25 [h]100 000h
TYPE OF CONTROLON/OFF
Body ColorBlack, Grey, White
Ingress Protection [IP]66
Mechanical Protection [IK]08
Main Feed AC [V]90 - 305
Weight [KG]32.00 kg
Housing
Body MaterialAluminium injection body
Body ColorBlack, Grey, White
RAL9005, 9022, 9016
FinishElectrostatic powder coated
Light technical data
Light SourceLED
Total Consumption [W]1200
Lumen Output [LM]144000 - 156000
Efficacy lm/W130
LED Color Temperature CCT [K]3000, 4000, 6500
Color Rendering Index [CRI]70
MacAdam step3
Beam Angle [°]15°, 18°, 30°, 40°, 60°, 90°, 86x105° asym
Light Distribution DIR/INDDIR
Technical data
TA [°C]-20 to +40
Ingress Protection [IP]66
Mechanical Protection [IK]08
Corrosion ClassC3, C4
Dimensions
Weight [KG]32.00 kg
