MOTUS 60 SURFACE
MOTUS 60 SURFACE

Dane ogólne
Application

Surface ceiling

Key Advantages

Slim modern design

Product ShapeTube
MountingSurface, Pendant
Dane elektryczne
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]8 - 16
IEC Protection ClassI
Optyka
Diffuser Material DesignLens
CONTROL SYSTEMON/OFF, DALI
LED LIFETIME Ta25 [h]L70B50 50.000h
Dane techniczne
Total Consumption [W]8 - 16
Lumen Output [LM]540 - 1300
Efficacy lm/Wup to 85
Body MaterialAnodized, Alu
Beam Angle [°]Table specification
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80, 90
MacAdam step3
LED LIFETIME Ta25 [h]L70B50 50.000h
Body ColorWhite 9016, Black 9005, Black/White
Ingress Protection [IP]20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Opis:

Subtle LED spotlight surface mount delivering an extreme slim design without compromises.

Key Advantages:

Slim modern design

Do pobrania:
Karta katalogowa:
1
Ilustracje techniczne:
1
Instrukcja montażu:
12
Certyfikaty:
1
Dane fotometryczne:
1
/soft4net/img/project/icons/DO WSZYSTKICH PRODUKTOW/CE.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/DALI.svg
/soft4net/img/project/icons/AB - TYPE OF CONTROL/ON_OFF.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_80.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/3000_90.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_80.svg
/soft4net/img/project/icons/Y + Z - CCT K + CRI/4000_90.svg
Dane ogólne
Application

Surface ceiling

Key Advantages

Slim modern design

Product ShapeTube
MountingSurface, Pendant
Dane elektryczne
Main Feed AC [V]220-240
Main Feed Frequency [Hz]50-60
Total Consumption [W]8 - 16
IEC Protection ClassI
Optyka
Diffuser Material DesignLens
CONTROL SYSTEMON/OFF, DALI
LED LIFETIME Ta25 [h]L70B50 50.000h
Dane techniczne
Total Consumption [W]8 - 16
Lumen Output [LM]540 - 1300
Efficacy lm/Wup to 85
Body MaterialAnodized, Alu
Beam Angle [°]Table specification
Light Distribution DIR/INDDIR
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80, 90
MacAdam step3
LED LIFETIME Ta25 [h]L70B50 50.000h
Body ColorWhite 9016, Black 9005, Black/White
Ingress Protection [IP]20
Mechanical Protection [IK]01
Main Feed AC [V]220-240
Obudowa
Body MaterialAnodized, Alu
Body ColorWhite 9016, Black 9005, Black/White
RALAny upon request
FinishMatt, Gloss
Dane techniczne oświetlenia
Light SourceCOB LED
Total Consumption [W]8 - 16
Lumen Output [LM]540 - 1300
Efficacy lm/Wup to 85
LED Color Temperature CCT [K]3000, 4000
Color Rendering Index [CRI]80, 90
UGR<19
MacAdam step3
Beam Angle [°]Table specification
Light Distribution DIR/INDDIR
Dane techniczne
TA [°C]0-25
Ingress Protection [IP]20
Mechanical Protection [IK]01
Corrosion ClassC3
